# 组件内转场
> **说明:**
> 从API Version 7开始支持。后续版本如有新增内容,则采用上角标单独标记该内容的起始版本。
组件转场主要通过transition属性进行配置转场参数,在组件插入和删除时进行过渡动效,主要用于容器组件子组件插入删除时提升用户体验(需要配合animateTo才能生效,动效时长、曲线、延时跟随animateTo中的配置)。
## 属性
| 名称 | 参数类型 | 默认值 | 参数描述 |
| -------- | -------- | -------- | -------- |
| transition | Object | - | 所有参数均为可选参数,详细描述见transition入参说明。 |
- transition入参说明
| 参数名称 | 参数类型 | 默认值 | 必填 | 参数描述 |
| -------- | -------- | -------- | -------- | -------- |
| type | TransitionType | TransitionType.All | 否 | 默认包括组件新增和删除。
> **说明:**
> 不指定Type时说明插入删除使用同一种效果。 |
| opacity | number | 1 | 否 | 设置组件转场时的透明度效果,为插入时起点和删除时终点的值。 |
| translate | {
x? : number,
y? : number,
z? : number
} | - | 否 | 设置组件转场时的平移效果,为插入时起点和删除时终点的值。
**说明:**
> x、y、z分别是横向、纵向、竖向的平移距离 |
| scale | {
x? : number,
y? : number,
z? : number,
centerX? : number,
centerY? : number
} | - | 否 | 设置组件转场时的缩放效果,为插入时起点和删除时终点的值。
**说明:**
> x、y、z分别是横向、纵向、竖向放大倍数(或缩小到原来的多少)
> centerX、centerY缩放中心点
> 中心点为0时,默认的是组件的左上角
|
| rotate | {
x?: number,
y?: number,
z?: number,
angle?: Angle,
centerX?: Length,
centerY?: Length
} | - | 否 | 设置组件转场时的旋转效果,为插入时起点和删除时终点的值。
**说明:**
> x、y、z分别是横向、纵向、竖向的旋转向量
> centerX,centerY指旋转中心点
> 中心点为0时,默认的是组件的左上角 |
- TransitionType枚举说明
| 名称 | 描述 |
| -------- | -------- |
| All | 指定当前的Transition动效生效在组件的所有变化场景。 |
| Insert | 指定当前的Transition动效生效在组件的插入场景。 |
| Delete | 指定当前的Transition动效生效在组件的删除场景。 |
## 示例
示例功能通过一个Button控制第二个Button的出现和消失,并通过transition配置第二个Button出现和消失的过场动画。
```ts
// xxx.ets
@Entry
@Component
struct TransitionExample {
@State btn1: boolean = false
@State show: string = "show"
build() {
Flex({ direction: FlexDirection.Column, alignItems: ItemAlign.Center,}) {
Button(this.show).width(80).height(30).backgroundColor(0x317aff).margin({bottom:50})
.onClick(() => {
animateTo({ duration: 1000 }, () => {
this.btn1 = !this.btn1
if(this.btn1){
this.show = "hide"
}else{
this.show = "show"
}
})
})
if (this.btn1) {
// 插入和删除配置为不同的过渡效果
Button() {
Image($r('app.media.bg1')).width("80%").height(300)
}.transition({ type: TransitionType.Insert, scale : {x:0,y:1.0} })
.transition({ type: TransitionType.Delete, scale: { x: 1.0, y: 0.0 } })
}
}.height(400).width("100%").padding({top:100})
}
}
```
![zh-cn_image_0000001174582850](figures/zh-cn_image_0000001174582850.gif)
