# PanGesture **PanGesture** is used to trigger a pan gesture, which requires a minimum 5 vp movement distance of a finger on the screen. > **NOTE** > > This gesture is supported since API version 7. Updates will be marked with a superscript to indicate their earliest API version. ## APIs PanGesture(value?: { fingers?: number; direction?: PanDirection; distance?: number } | [PanGestureOptions](#pangestureoptions)) **Parameters** | Name| Type| Mandatory| Description| | -------- | -------- | -------- | -------- | | fingers | number | No| Minimum number of fingers to trigger a pan gesture. The value ranges from 1 to 10.
Default value: **1**| | direction | PanDirection | No| Pan direction. The enumerated value supports the AND (&) and OR (\|) operations.
Default value: **PanDirection.All**| | distance | number | No| Minimum pan distance to trigger the gesture, in vp.
Default value: **5.0**
**NOTE**
If a pan gesture and tab swipe occur at the same time, set **distance** to **1** so that the gesture can be more easily recognized.| ## PanDirection enums | Name| Description| | -------- | -------- | | All | All directions.| | Horizontal | Horizontal panning.| | Vertical | Vertical panning.| | Left | Panning to the left.| | Right | Panning to the right.| | Up | Panning up.| | Down | Panning down.| | None | Panning disabled.| ## PanGestureOptions The attributes of the pan gesture recognizer can be dynamically modified using the **PanGestureOptions** API. This avoids modifying attributes through state variables, which will cause the UI to be refreshed. PanGestureOptions(value?: { fingers?: number; direction?: PanDirection; distance?: number }) **Parameters** | Name | Type | Mandatory| Description | | --------- | ------------ | ---- | ------------------------------------------------------------ | | fingers | number | No | Minimum number of fingers to trigger a pan gesture. The value ranges from 1 to 10.
Default value: **1**| | direction | PanDirection | No | Pan direction. The enumerated value supports the AND (&) and OR (\|) operations.
Default value: **All**| | distance | number | No | Minimum pan distance to trigger the gesture, in vp.
Default value: **5.0**
**NOTE**
If a pan gesture and tab swipe occur at the same time, set **distance** to **1** so that the gesture can be more easily recognized.| **APIs** | Name| Description| | -------- | -------- | | setDirection(value: PanDirection) | Sets the direction.| | setDistance(value: number) | Sets the distance.| | setFingers(value: number) | Sets the number of fingers.| ## Events | Name| Description| | -------- | -------- | | onActionStart(event: (event?: [GestureEvent](ts-gesture-settings.md)) => void) | Callback invoked when a pan gesture is recognized.| | onActionUpdate(event: (event?: [GestureEvent](ts-gesture-settings.md)) => void) | Callback invoked when the pan gesture status is updated.| | onActionEnd(event: (event?: [GestureEvent](ts-gesture-settings.md)) => void) | Callback invoked when the finger used for a pan gesture is lift.| | onActionCancel(event: () => void) | Callback invoked when a tap cancellation event is received after a pan gesture is recognized.| ## Example ```ts // xxx.ets @Entry @Component struct PanGestureExample { @State offsetX: number = 0 @State offsetY: number = 0 build() { Flex({ direction: FlexDirection.Column, alignItems: ItemAlign.Center, justifyContent: FlexAlign.SpaceBetween }) { Text('PanGesture offset:\nX: ' + this.offsetX + '\n' + 'Y: ' + this.offsetY) } .height(100).width(200).padding(20).border({ width: 1 }).margin(80) .translate({ x: this.offsetX, y: this.offsetY, z: 5 }) .gesture( PanGesture({}) .onActionStart((event: GestureEvent) => { console.info('Pan start') }) .onActionUpdate((event: GestureEvent) => { this.offsetX = event.offsetX this.offsetY = event.offsetY }) .onActionEnd(() => { console.info('Pan end') }) ) } } ``` ![en-us_image_0000001256978371](figures/en-us_image_0000001256978371.gif)
